RED DOT SIGHT
APEX G11
Red dot sight
A clear reference.
An uncluttered view.
APEX G11 pairs an illuminated 2 MOA aiming dot with adjustable brightness and motion activation in an aluminium housing.
As low as $499.00
01 / PRODUCT OVERVIEW
A clear reference.
An uncluttered view.
APEX G11 pairs an illuminated 2 MOA aiming dot with adjustable brightness and motion activation in an aluminium housing.
Dot size, brightness selection and power behaviour are grouped separately for a clear view of the sight’s configuration.
Discuss this modelILLUMINATED DOT
AIMING REFERENCE
A 2 MOA dot in a 1× view.
An illuminated 2 MOA dot provides the aiming reference. The 1× optical format is paired with ten daylight brightness levels and two night-vision levels.
- Magnification
- 1×
- Click value
- 1/2 MOA
- Dot size
- 2MOA
- Brightness settings
- 2(NV)+10
MOTION & POWER
Ready when movement returns.
Motion activation wakes the sight from its sleep state when movement is detected. Brightness selection and operating conditions affect battery duration.
- Motion activation
- Yes
- Battery life
- 100,000 Hours
CONSTRUCTION
An aluminium housing for the optical system.
The 6061-T6 aluminium housing is specified with IP67 ingress protection. Model-specific shock resistance and operating temperatures are listed below.
- Housing Material
- Aircraft Grade Aluminum 6061T6
- Ingress protection
- IP67
- Shock resistance
- 1200g
- Operating temperature
- -30°C to +60°C
TECHNICAL SPECIFICATIONS
The complete specification.
APEX G11
Red dot sight
Optics & viewing
| Magnification | 1× |
|---|---|
| Exit Pupil Dia | 22 |
| Dot size | 2MOA |
Reticle & controls
| Parallax setting | 100YDS / 1' |
|---|---|
| Click value | 1/2 MOA |
| Windage Elevation (Up Down) | 〉140MOA |
| Windage Elevation (Right Left) | 〉140MOA |
| Brightness settings | 2(NV)+10 |
| Motion activation | Yes |
Construction & environment
| Housing Material | Aircraft Grade Aluminum 6061T6 |
|---|---|
| Ingress protection | IP67 |
| Shock resistance | 1200g |
| Operating temperature | -30°C to +60°C |
Power & connectivity
| Battery life | 100,000 Hours |
|---|
